BenQ PH550 Super Narrow Bezel Signage (For Video Wall) 55″
$7,699.00
B-B 5.3 mm
high brightness (800 cd/m2 )
DVI daisy chain
multiple display administrator
color calibration
- Description
Description
Liven Up Your Information Display Vividly
BenQ PH550 digital signage with 800 nits high brightness and 5.3mm super narrow bezel is perfect for your seamless video wall application
key features
- B-B 5.3 mm
- high brightness (800 cd/m2 )
- DVI daisy chain
- multiple display administrator
- color calibration
Super Narrow Bezel
The super-narrow bezel of the PH550 achieves a incredible 5.3mm bezel-bezel gap to provide the audience with a virtually seamless viewing experience. As screens are close to each other, they bring viewers closer to your message as well.*
*Actual bezel-to-bezel dimensions may exceed the listed minimum values (5.3mm for PH550) due to different tiling methods.
24 / 7 Operation
The P Series has an amazing average life of 50,000 hours – enough for several years of non-stop service. With the reliable industrial-class performance and sturdy build, the BenQ digital signage displays are in fact more economic then consumer models.
Optimized for Portrait Mode
BenQ puts extra attention on scenarios in which portrait mode communicates better. The PID panel employs a structure featuring more solid fixing points on all edges to prevent “Mura” image distortion common on vertically positioned consumer displays.
DisplayPort
DisplayPort is a new standard for digital audio/video transmission. With the whopping 10.8Gbps bandwidth, the DisplayPort keeps your contents attractive, distortion-free in longer distances than conventional DVI and HDMI.
Color Calibration
The optional BenQ Color Calibration solution is great for managing a number of displays. It unifies the color profile of every screen for the best aggregated presentation through a central PC without the need to manually adjust each unit. A true time-saver.
MDA
The MDA (Multiple Display Administrator) application controls multiple & discrete displays simultaneously through the local network or serial port; it also monitors the health of displays and coordinates a sequential startup to prevent power surges.*
*Controlling up to 98 units (RS232), unlimited units (LAN)
High Brightness
For compelling digital signage in shopping malls, transportation hubs, and sports and entertainment facilities, the BenQ PH550 is a smart choice. 800 cd/m² brightness and 1400:1 contrast ratio assure excellent visibility, even in window-facing indoor settings with high ambient light.
10×10 Video Wall
Designed for large video walls, the P Series supports the array configuration of up to 10×10 displays in OSD setting with a splitter. The feature plus the super-thin bezel is bound to bring your audience a colossal, immersive viewing experience.
RS232 / LAN Control
BenQ P Series supports remote administration via the built-in RJ45 Ethernet or the RS232 serial interface. Routine tasks such as OSD settings and firmware upgrades can be performed on the control server to the daisy-chained displays.
10-bit PID Panel
The panel is capable of displaying 10-bit levels for each primary color, that’s 1073.7-million colors in total. This helps producing smooth, rich images with no visible color banding for extremely vivid and effective contents.
Digital Daisy Chain
This feature allows you to deliver high-quality mirrored contents to different locations, or to build a huge multi-display, single-image video wall through one DVI port on the controller PC without the need for splitters.
Anti-Image Retention
In commercial environments where images would stay for hours, image retention becomes a problem on consumer displays. PID panels designed for digital signage prevents the burned-in effect even after an extended period of usage.
Panel  |
|||||||||||
| LCD Size (inch) | 55″ | ||||||||||
| Light source | LED | ||||||||||
| Resolution (Pixels) | FHD 1920 x 1080 (pixels) | ||||||||||
| Aspect Ratio | 16 : 9 | ||||||||||
| Native Contrast Ratio (typ) | 1400:1 | ||||||||||
| Response Time (G-to-G) | 10ms | ||||||||||
| Panel Bit | 10 bit , 1.06B colors | ||||||||||
| Light Life (Typical) | 50,000 hrs (typ.) | ||||||||||
| Orientation | Landscape / Portrait | ||||||||||
| Frame Rate | 60Hz | ||||||||||
| Viewing Angle (Horizontal / Vertical) | 178 degree (H) / 178 degree (V) | ||||||||||
| Brightness (Typical) | 800 cd/m² | ||||||||||
| Power |
|||||||||||
| Power Supply | 100 V ~ 240 V, 50 Hz / 60 Hz | ||||||||||
| Power Consumption (Maximum / Standby) | <345W, 310W (Typ.) | ||||||||||
| I/O Connection |
|||||||||||
| Power (AC) Input/Output | Yes | ||||||||||
| Audio line-in | Yes | ||||||||||
| Power Switch | Yes | ||||||||||
| Composite Video In/ Out | Yes | ||||||||||
| Component video (RCA) | Yes | ||||||||||
| External Speaker Out (L/R) | Yes | ||||||||||
| D-sub In/ Out | Yes | ||||||||||
| HDMI (Type A ) | Yes x 2 | ||||||||||
| DisplayPort Input | Yes | ||||||||||
| RS232 In/ Out | Yes | ||||||||||
| RJ45 Port | Yes | ||||||||||
| AC Power Switch | Yes | ||||||||||
| DVI-D In/ DVI-I Out | Yes | ||||||||||
| Mechanical |
|||||||||||
| Dimension (WxHxD) (mm) | 1215.2 x 686 x 115.25 mm | ||||||||||
| Weight (Without Packing / With Packing) (kg) | 32/40.5 kg | ||||||||||
| Bezel Width (Top / Bottom / Left / Right) (mm) | 3.4/1.9/3.4/1.9 mm | ||||||||||
| Feature |
|||||||||||
| On-Screen Display Languages | English/ French/ Portuguese/ Spanish/ Simplified Chinese/ Traditional Chinese(6 Languages) | ||||||||||
| Software |
|||||||||||
| Color Calibration support | Supported OS: 1. Windows XP 32/64 bit 2. Windows Server 2003 3. Windows Vista 32/64 bit 4. Windows 7 32/64 bit. |
||||||||||
| Multiple Display Control (MDA) support | Supported OS: 1. Windows XP 32 bit 2. Windows Vista 32/64 bit SP2 3. Windows 7 32/64 bit |
||||||||||
| Certification |
|||||||||||
| TAA Compliant | No | ||||||||||
| Accessories |
|||||||||||
| Standard |
|
||||||||||
