Samsung QB98R
$25,680.00
Diagonal Size 98″
TypeEdge LED BLU
Resolution3840*2160 (4K UHD)
Pixel Pitch(mm)0.562 x 0.562 (mm)
Active Display Area(mm)2158.848(H) x 1214.352(V)
Brightness(Typ.)350 nit
Contrast Ratio4000:1
Viewing Angle(H/V)178/178
Response Time(G-to-G)6ms(Typ.)
Display Colors16.7M(True Display)1.07B(Ditherd 10bit)
Color Gamut72%
Operation Hour24/7
Haze25%
- Description
Description
QB98R
UHD display that engages customers with lifelike images through innovative and unique picture-enhancing features.
- Engage customers with lifelike images through ultra high-definition resolution
- Deliver UHD-level picture quality even with lower resolution content through innovative UHD upscaling technology and unique picture-enhancing features
Features
Time to upscale your display
Samsung’s new QB98R displays cut through the clutter to deliver best-in-class UHD resolution as well as intelligent UHD upscaling all in a slim design.
Incredible 4K picture quality
Samsung’s new QB98R provides ultra high-definition 4K resolution, creating lifelike images with sharper picture quality than ever before.
Intelligent UHD upscaling
Samsung’s cutting-edge intelligent UHD upscaling technology performs edge restoration and noise reduction to deliver perfect UHD picture quality even with lower resolution content. This “future-proof” solution ensures best-in-class picture quality regardless of the original content resolution.
Perfect view with non-glare display
The QB98R features reliable, non-glare panels that provide better visibility from all angles, anytime of day allowing businesses to deliver accurate information 24/7 in locations where clear and accurate information is crucial such as airports and commuter stations.
Powerful, all-in-one solution
SSSP is an all-in-one solution that simplifies installation and maintenance. With Tizen 4.0, businesses can enjoy easy development, reinforced capability with multiple web formats and standards and secured protection.
Samsung Workspace secured by Knox
With security provided by Knox, the displays feature Samsung Workspace which supports wireless cloud service access and control of a PC without needing a physical connection. Samsung Workspace simplifies meeting spaces while also improving security.
Maintain Continuous Display Performance
Beyond security and content management, QB98R users can trust the displays’ remote management for fast, efficient issue mitigation. Users can monitor and diagnose irregularities – both on their own and with help from Samsung’s 24/7 Network Operations Center – from any location.
WiFi and Bluetooth built-in
Built-in WiFi and Bluetooth allow for more personalized and interactive services as well as simplifying how businesses showcase content. Whether it’s to make networking simpler or enabling interactive beacon technology in-store, QB98R displays help businesses move into the future of retail.
* Image is for illustrative purposes only, specific application or program may have to be developed for the depicted usage scenario.
Specs
Panel
- Diagonal Size98″
- TypeEdge LED BLU
- Resolution3840*2160 (4K UHD)
- Pixel Pitch(mm)0.562 x 0.562 (mm)
- Active Display Area(mm)2158.848(H) x 1214.352(V)
- Brightness(Typ.)350 nit
- Contrast Ratio4000:1
- Viewing Angle(H/V)178/178
- Response Time(G-to-G)6ms(Typ.)
- Display Colors16.7M(True Display)1.07B(Ditherd 10bit)
- Color Gamut72%
- Operation Hour24/7
- Haze25%
Display
- Dynamic C/RMega
- H-Scanning Frequency30 ~ 81kHZ
- V-Scanning Frequency48 ~ 75HZ
- Maximum Pixel Frequency594MHz
Sound
- Speaker TypeBuilt in Speaker(10W + 10W)
Connectivity
Input
- RGBDVI-D, Display Port 1.2 (1)
- VideoHDMI 2.0 (2)
- HDCPHDCP2.2
- AudioStereo mini Jack, DVI, HDMI
- USBUSB 2.0 x 2
Output
- RGBHDMI 2.0 (Loop-out)
- AudioStereo mini Jack
- External ControlRS232C(in/out) thru stereo jack, RJ45
- External SensorIR
Power
- TypeInternal
- Power SupplyAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption
- Max[W/h]528
- Typical[W/h]372
- BTU(Max)480
- Sleep mode1800.5
- Off mode0.5
Mechanical Specification
Dimension (mm)
- Set2194.2 x 1249.8 x 71.6 (w/o handle) 2194.2 x 1249.8 x 75.3 (w/ handle)
- Package2500 x 1618 x 815
Weight (kg)
- Set77.1
- Package149.4
- VESA Mount (mm)900×600
- Stand TypeNo
- Bezel Width (mm)15.2mm(U/L/R), 15.2mm(B)
Operation
- Operating Temperature0 ℃ ~ 40 ℃
- Humidity10 % ~ 80 %
Feature
- Key FeaturesUHD Signage Display Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
- Special FeaturesH/W: Temperature Sensor,Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain(HDCP2.2:4EA,HDCP1.4:7EA), Wi-Fi/BT S/W: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)
Internal Player
- ProcessorCoretex A72 1.7GHz Quad-Core CPU
- On-Chip Cache MemoryL1 Instruction Cache : 48KB L1 Data Cache : 32KB L2 Cache : 2MB
- Clock Speed1.7GHz
- Main Memory Interface2.5GB LPDDR4 1.5GHz 64bit
- GraphicsGraphic resolution : 1920×1080 Output resolution : 3840×2160 (Scale up from graphic processing result.)
- Storage (FDM)8GB (3.88GB Occupied by O/S, 4.12GB Available)
- Multimedia*Video Decoder : MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9 *Audio Decoder : AC3 (DD), MPEG
- IO PortsUSB 2.0
- Operating SystemTizen 4.0 (VDLinux)
Certification
- Safety60950-1
- EMCClass A
Accessory
- IncludedQuick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional
- Stand–
- MountWMN9500SD
- Specialty–
Media Player
Media Player
- Media PlayerN/A
